Contact Supplier
Mr. Aaron
Leave a message Mr. AaronWhat can I do for you?
Shenzhen Cxcolor Optoelectronics Co., LTD.
| Payment Type: | L/C,T/T,D/P,Paypal,Money Gram,Western Union |
|---|---|
| Incoterm: | FOB,CFR,CIF |
| Min. Order: | 1 Square Meter |
| Delivery Time: | 18 Days |
Basic Info
Model No.: P10
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 300W / m²
Display Type: LED Video Display
Application: Advertising
Certification: CE, RoHS, UL, CCC, ETL
Driving IC: MBI5124
Working Temperature: -30ºC~60ºC
Working Humidity: 10~95%RH
Input Voltage(V): AC 110V-220V +/-10%
Maintenance: Rear Service
Controller: Novastar / Linsn
LED Chip: Epistar/Nationstar
Scaning Mode: 1/2scan
Pixel Density: 10000dot/sqm
Pixel: 10mm
Additional Info
Packaging: Flight or wooden package case for 5 to 1
Productivity: 1000
Brand: CXCOLOR
Transportation: Ocean,Land,Air
Place of Origin: China
Supply Ability: 5000sqm/moth
Certificate: CE, FCC,RoHS
HS Code: 8528591090
Port: Shenzhen,Guangzhou,Shanghai
Product Description
1. Led Display Module has multi-language operation interface: English, French, Italian, Spanish etc..
2. Outdoor Led Display Module Display function: current temperature (Centigrade), time, date, graphics, animations (including GIF, 3D) and text .
3. All Cross Screen operations can be done very easily and conveniently!
4. Led Board Display with low power consumption.
5. Led Display Video Billboard has 4 grades of brightness and Led Screen Display support automatic adjustment or programmed control in different period.6. Full Color Led Display with 5 grades of speeds for text, 8 grades of moving speeds for animation.
Product Application
Product Paramater
1/2scan
Unit Module Product Name
Super Bright P10 Module Cross Screen Led Display
Pixel Pitch
10mm Module size
320*160mm Module resolution
32*16dots Density
10000dot/sqm Diving method
Led Standard
SMD3535 Pixel configuration
1R1G1B Cabinet Cabinet material
Iron Cabinet size
Customized
Cabinet weight
35kg
Main parameter
Best View distance
4-100m
Gray scale
16bits
Refresh Rate
1200HZ
Protection Degree IP65
Color temperature
6500K
View Angle
H:±150 degree V:±120 degree
Colors
＞16.7M
Max Consumption
750W/m²
Average Power
250W/m²
Working temperature
- 20℃~+50℃
Driving device
Constant current
Mtbf
10,000Hours
Life span
100,000Hours
Out-of control point
＜0.0001
Package case: Flgiht or wooden package case for 5 to 1
Our Services
1.The price depends on the quantity.We can offer you the best competitive price with the same even better quality.
2.Good after sale service: We can response in time if customers have questions about the installation , usage and maintenance ect.
3. Your inquiry will be replied by well-trained and experienced staffs in 24 hours.
4. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
5. Help you design OEM&ODM or any your customized lightings and put into production.
6. Distributorship are offered for your unique design and some our current models
7.Your sales area, ideas of design and all your private information will be well protected
Product Categories : Cross Screen
